AMC MECANOCAUCHO支架137628规格
Type | 14 - 2 holes |
|
Tightening torque Max (Nm) | 71 | |
Weight(gr) | 643 | |
Code | 137628 | |
Max. Load(kg) | 500 | |
Shore | 65 Sh |
AMC MECANOCAUCHO支架介绍
AMC-Mecanocaucho® 锥形件通过剪切压缩作用于橡胶。由两个平行的锥形金属件组成。配有两个垫圈，一个作为阻止件，另一个用于定心。
技术特性
AMC-Mecanocaucho® 锥形弹性减振器为安全且稳定的元件。它们可防止被悬挂元件倾斜，同时具有足够的弹性以避免通过结构传递噪音和振动。
产品随附止动垫圈与定心垫圈。即使在极端负载下，也能避免超出 Mecanocaucho® 锥形件允许范围的偏移。
垫圈可保护天然橡胶（具有高弹性与高耐久性）免受臭氧与老化、金属撞击及滴落油污的损害。带定心垫圈的 AMC-Mecanocaucho® 锥形减振器的典型位移曲线相当线性，随载荷增加而逐步增大。因此它们能够安全地缓冲高达三倍最大允许载荷的过载。
The AMC-Mecanocaucho® cones work the rubber in shear compression. They are composed of two parallel conical metal parts. They have two washers, one as a buffer and the other for centering.
Technical characteristics
The AMC-Mecanocaucho® Cone mounts are safe and stable elements. They do not allow the suspended elements to tilt, while being flexible enough to avoid the transmission of noise and vibration through the structure.
They are supplied with stop and centering washers. This renders deflection above the limits of the Mecanocaucho® Cones impossible, even at extreme loads.
The washers protect the natural rubber (which is highly elastic and highly resistant) from ozone and aging, as well as from metal knocks and dripping oil. The characteristic deflection curves of the AMC-Mecanocaucho® Cone mounts with centering washer are quite linear, increasing progressively as the load increases. Thanks to this they can safely dampen overloads of up to three times the maximum admissible load.
AMC MECANOCAUCHO支架其他常用型号：
AMC MECANOCAUCHO 137921
AMC MECANOCAUCHO 137922
AMC MECANOCAUCHO 137925
AMC MECANOCAUCHO 137930
AMC MECANOCAUCHO 137628
AMC MECANOCAUCHO 137935
AMC MECANOCAUCHO 137936
AMC MECANOCAUCHO 137937
AMC MECANOCAUCHO support NEW + ORIGINAL+ ONE YEAR WARRANTY
爱泽工业成立于2010年，定位于向制造工业提供高端制造技术和设备。代理经营世界优质的电气自动化、机械与传动、流体控制、仪器仪表、工具等产品。作为电气，液压以及气动解决方案的合作伙伴，我们利用我们的全球协作团队，为客户提供先进解决方案，市场知识以及相关增值服务来帮助优化客户的工作效率，提高可靠性和安全性，致力于成为工业产品和解决方案的优质渠道。
如果有任何关于AMC MECANOCAUCHO支架137628的疑问，请随时与我们沟通（021-31006702）。我们将尽全力解决您的问题。
If you have any question for AMC MECANOCAUCHO products, please feel free to dial 0086-21-3100 6702/ send request email to sales@ize-industries.com / browse our website:www.ize-industries.com.
