PARKER阀CM2PPVHT技术参数
Technical Specifications | |
Maximum Flow Rate | 60 L/MIN |
Port Connection | NG06 / CETOP 03 |
Function | From manifold to directional valve, check valve in channel P |
Mounting Type | Sandwich Plate |
Product Series | Check Valve |
Maximum Operating Pressure | 350 bar |
Actuation Type | Mechanical |
Body Material | Steel |
Configuration | Check Valve in Port A |
Cracking Pressure | 0.5 bar |
Flow Direction | Manifold to Directional Valve |
Maximum Operating Temperature | 70 °C |
Maximum Ambient Temperature | 70 °C |
Minimum Operating Temperature | -20 °C |
Minimum Ambient Temperature | -20 °C |
Seal Material | FPM |
Mounting Position | Unrestricted |
Weight | 0.7 kg |
Maximum Flow Rate | 60 L/min |
Maximum Kinematic Viscosity | 400 cSt |
Minimum Kinematic Viscosity | 20 cSt |
For Fluid Type | Hydraulic Oil According to DIN 51524, Hydraulic Oil |
Filter Efficiency Rating | ISO 4406 18/16/13 |
Application | Industrial Hydraulic |
Technology | Hydraulics |
Media | Hydraulic Oil |
Brand | Parker |
Operation Type | Direct |
Interface Type | ISO 4401 |
Port Connection | NG06 / CETOP 03 |
Division | Hydraulic Valve Systems Division Europe |
Maximum Fluid Temperature | 70 °C |
Minimum Fluid Temperature | -20 °C |
Mounting Style | DIN 24340, ISO 4401, CETOP RP121, NFPA D03 |
Valve Type | Check Valve |
PARKER阀CM系列介绍
CM系列直动式单向阀采用夹层式设计，是夹层式阀产品的一部分，可轻松配置传统的叠层式系统。此外，它们还具有高性价比。
CM系列提供NG06和NG10两种尺寸。根据所需功能，P、T、A和B端口可安装一个或两个单向阀。单向阀的数量和流向可通过订购代码选择。
市场：
• 工业
• 机床
• 橡胶轮胎加工
特点/优势：
• 阀体内止回阀的布置方式有 8 种选择 - 液压切换用途广泛
• 阀体采用钢材制成 - 强度更高，更耐用
• 旋转阀门即可切换功能 - 操作简便
• 大多数型号交货期短 - 无需仓储
• 两种尺寸：
- CM2 - NG06 (CETOP 03)
- CM3 - NG10 (CETOP 05)
• 最大工作压力 350 bar
应用：
• 适用于一般液压应用
• 机床
• 轮胎压机
Parker direct operated check valves series CM in sandwich design are part of Parker's complete range of sandwich plate valves and ensure an easy configuration of conventional stack systems. Additionally they provide a very good price-performance ratio.
Series CM is available in two sizes, NG06 and NG10. Depending on the function required, one or two check valves are arranged in ports P, T, A, and B. Number and flow direction can be selected from the ordering code.
Markets:
• Industrial
• Machine tools
• Rubber & tire processing
Features/Benefits:
• 8 options for the arrangement of the check valve in the body - multitude of uses for hydraulic switching
• Valve bodies are made of steel - extra strength and durability
• Function can be changed by turning the valve - easy handling
• Short delivery time for most versions - no warehousing necessary
• Two sizes:
- CM2 - NG06 (CETOP 03)
- CM3 - NG10 (CETOP 05)
• Maximum operating pressure 350 bar
Applications:
• Suitable for general hydraulic applications
• Machine tools
• Tire presses
PARKER阀CM系列选型
PARKER阀CM系列其他常用型号：
PARKER CM2PPVHT
PARKER CM2AAFVHT
PARKER CM2BBVHT
PARKER CM2PPVHT
PARKER CM2PTVHT
PARKER CM2TTVHT
PARKER CM3BBVHT
PARKER CM3PPVHT
PARKER CM3TTVHT
PARKER CM2BBFVHT
PARKER CM3BBFVHT
PARKER CM3AAVHT
PARKER CM2AAFV
PARKER CM2AAV
PARKER CM2BBFV
PARKER CM2BBV
PARKER CM2DDFV
